Description
APD UHV 28S
Sku: 100793
Manufactured in Australia
APD UHV 28S
Operating within a 32-bit ARM architecture, the UHV ESCs are designed to deliver fast throttle response that is linear over the complete output range of up to 45 kW. APD's proprietary developed firmware ensures unmatched low-throttle and starting characteristics. The ramp characteristics can be configured for fast response or drive-train protection. Advanced features include PWM-frequency dithering to avoid PWM-commutation synchronisation, adaptive motor timing advance and proprietary developed Active Phase-Current Demagnetisation (APCD). APCD along with Synchronous rectification ensure maximum ESC efficiency is achieved.
Specifications
- Input Voltage: Up to 28S (120V)
- Rated Phase Current: Up to 300 A continuous* current with airflow
- Peak Phase Current: 400 A burst current
- Weight: 0.74kg
- Dimensions: 180x100x27mm
What's included:
APD UHV 28S:
1x - UHV 28S
More information:
Documentation: https://docs.powerdrives.net/products/uhv
CAD Model: https://docs.powerdrives.net/downloads/3d-model-downloads#uhv
