Description
APD HV 14S
Sku: 100788
Manufactured in Australia
APD HV_Pro 14S
The HV_Series 14S ESC can deliver 240 A of continuous current with a burst current capability of 360 A. These ESCs have over 4 x the Silicon Junction area compared to other similar-sized ESCs.
Operating within a 32-bit ARM architecture, the ESC is designed to deliver fast throttle response that is linear over the complete output range of up to 20 kW. APD's proprietary developed firmware ensures unmatched low-throttle and starting characteristics. The ramp characteristics can be configured for fast response or drive-train protection. Advanced features include PWM-frequency dithering to avoid PWM-commutation synchronisation, adaptive motor timing advance and proprietary developed Active Phase-Current Demagnetisation (APCD). APCD along with Synchronous rectification ensure maximum ESC efficiency is achieved.
Specifications
- Input Voltage: Up to 14S (60 V)
- Rated Phase Current: Up to 240 A continuous* current with airflow
- Peak Phase Current: 360 A burst current
- Weight: 0.26kg
- Dimensions: 96x52x26mm
What's included:
APD HV 14S:
1x - HV 14S
More information:
Documentation: https://docs.powerdrives.net/products/hv_pro
CAD Model: https://docs.powerdrives.net/downloads/3d-model-downloads#hv-14s
