Description
APD products are intended for commercial, institutional, and government use only.
Designed and manufactured in Australia using only the highest quality components, ensuring no sacrifice in reliability
-
Proprietary firmware designed in Australia
-
Plug and play firmware
-
Up to 6S (25.5 V) capable
-
Up to 40 A continuous* output current
-
100 A Burst current
-
True 10-bit resolution
-
Virtually no setup time, with a simple motor reverse solder tab
-
Auto-detect ProShot or DShot
-
ProShot1000 capable (1Mbs/s)
-
DShot300 to DShot1200 capable (0.3-1.2Mbs/s)
-
Up to 750,000 eRPM
-
Motor agnostic
-
Auto PWM output frequency
-
Auto timing advance
-
Telemetry output
-
Automatic current limiting and over-temperature protection
-
LED indication
-
Digital commands over ProShot (including anti-turtle mode)
-
Digital commands over DShot
-
Bare-PCB design to allow maximum integration within the end setup
-
8-Layer PCB to ensure minimal track resistance
Additional Information
Weight: 0.003kg
Dimensions: 16x30x5mm
Documentation: docs.powerdrives.net
CAD Model: 40F3
